Suitable for producing HDPE/LDPE flat bags
Email：a18767794044@gmail.com
WhatsApp：+86 151 6779 4044
Suitable for producing HDPE/LDPE flat bags
1. Computerized automatic control, automatic counting and settable counting alarm, high efficiency, saving manpower and time;
2. Fully automatic one-time completion from film roll to finished bag;
3. Servo motor with fixed length and photoelectric tracking, accurate and stable, feeding is photoelectric controlled;
4. Uses heat sealing and cold cutting device, intelligent temperature control system ensures firm and flat bag sealing;
5. Uses frequency converter for speed regulation;
|
Model |
800Model |
Electrical Appliances |
Wenzhou Zhengtai |
|
Maximum bag-making width |
700mm |
Computer |
Zhongxin |
|
Maximum bag length |
3000mm |
Color Mark Photoelectric Eye |
Longyou |
|
Production speed |
20–120 pieces/minute |
Feeding photoelectric sensor |
Longyou |
|
Cut thickness |
0.01mm-0.30mm |
Temperature Controller |
Wenzhou Dechuang |
|
Dimensions (L×W×H) |
2300*1500*1400 |
Hot Knife |
Copper Knife |
|
Main motor |
Shanghai Henglie Motor 1.5kW |
Cutting blade |
800 |
|
Frequency converter |
Kewo 1.5kW |
Static electricity box |
16kv |
|
Feeding motor |
DC Motor 400W*1 |
Static electricity bar |
600mm pieces |
|
Main Shipping Fee |
Servo motor |
Mat device |
yes |
|
Then add the material |
1 mechanical shaft |
Machine exterior casing |
Powder coating and baking paint process |
|
Total power of the entire machine |
8KW |
Voltage |
220V/50HZ |
This machine is suitable for heat sealing and cutting of high-density polyethylene (HDPE), low-density polyethylene (LDPE), and polypropylene (PP) plastic films, making it an ideal machine for producing flat bags from high and low pressure plastic films.
The new design of super high-speed vest bag bag making machine, specially designed for the production of T-shirt bags, second-line super high-speed production, easy to operate, high yield. Special servo-motor drive and motion control technology.
This machine is suitable for heat-cutting bags from BOPP, PP, PE, POF and other film materials.
