This machine is suitable for BOPP, PP, PE, POF express bags, etc.
Hot-cut bag making of film materials is widely used in the production of daily general packaging. It has the characteristics of fast speed, beautiful and firm edge sealing, convenient adjustment, and simple maintenance.
|
Model |
RD720 |
RD550 |
RD550Z |
|
Power supply |
220V |
220V |
220V |
|
Total power |
4600W |
4600W |
4600W |
|
Average power |
2000W |
1700W |
1700W |
|
Bag width |
60-690mm |
60-520mm |
50-520mm |
|
Bag length |
45-999mm |
45-999mm |
25-500mm |
|
Bag Making Speed |
30-200P/min |
30-220P/min |
30-220P/min |
|
Weight |
730kg |
650kg |
680kg |
|
Machine length |
3300mm |
3010mm |
3010mm |
|
Machine width |
1100mm |
940mm |
940mm |
|
Machine height |
1275mm |
1225mm |
1225mm |
Suitable for producing HDPE/LDPE flat bags.
The new design of super high-speed vest bag bag making machine, specially designed for the production of T-shirt bags, second-line super high-speed production, easy to operate, high yield. Special servo-motor drive and motion control technology.
1. This machine adopts an advanced Taiwan Welink touch screen display, advanced PLC computer program, automatic deviation correction control program, and the whole machine adopts frequency conversion speed regulation.
