Suitable for producing HDPE/LDPE flat bags and square bottom bags.
Email：a18767794044@gmail.com
WhatsApp：+86 151 6779 4044
Suitable for producing HDPE/LDPE flat bags and square bottom bags.
1. Computerized automatic control, automatic counting, and settable counting alarm; high efficiency, saving manpower and time.
2. Fully automatic one-time completion from roll film to finished bag.
3. Servo motor with fixed length and photoelectric tracking; accurate and stable; photoelectric control for feeding.
4. Employs a heat-sealing and cold-cutting device; intelligent temperature control system ensures a firm and flat bag seal.
5. Uses a frequency converter for speed regulation.
|
Model |
Type 800 |
Electrical Appliances |
Wenzhou Zhengtai |
|
Maximum bag-making width |
700mm |
Computer |
Zhongxin |
|
Maximum bag length |
3000mm |
Color Mark Photoelectric Eye |
Longyou |
|
Production speed |
20-120 reps/minute |
Feeding photoelectric sensor |
Longyou |
|
Cut thickness |
0.01mm-0.30mm |
Temperature Controller |
Wenzhou Dechuang |
|
Dimensions (L×W×H) |
2300*1500*1400 |
Hot Knife |
Copper Knife |
|
Main motor |
Shanghai Henglie Motor 1.5kW |
Cutting blade |
800 |
|
Frequency converter |
Kevo 1.5kw |
Static electricity box |
16kv |
|
Feeding motor |
DC motor 400W*1 |
Static electricity bar |
600mm 2pieces |
|
Main Shipping Fee |
Servo motor |
Mat device |
yes |
|
Then add the material |
1 mechanical shaft |
Machine exterior casing |
Powder coating and baking paint process |
|
Total power of the entire machine |
8KW |
Voltage |
220V/50HZ |
Suitable for producing HDPE/LDPE flat bags.
This machine is suitable for heat-cutting bags from BOPP, PP, PE, POF and other film materials. It is widely used in the production of everyday general packaging and features high speed, beautiful and strong sealing, convenient adjustment and simple maintenance.
The new design of super high-speed vest bag bag making machine, specially designed for the production of T-shirt bags, second-line super high-speed production, easy to operate, high yield. Special servo-motor drive and motion control technology.
